100mtr CCA cat 6 network Cable

Specifications

• Model Name : ZEB-C4PCAT6CCA-100M-PRIME
• No. of wires : 4 pairs
• Cable length : 100 meter
• Conductor material  : 24 AWG CCA
• Construction diameter : 0.45mm
• Insulation material : High Density Polyethylene
• Insulation thickness : 0.2mm
• Insulation diameter : 0.90mm
• Jacket material : PVC
• Jacket thickness : 0.2 mm
• Jacket diameter : 6.1mm
• Jacket color : Gray
• Separator : PE Central cross separator
• Conductor resistance : <9.38Ω/km at 20°C
• Weight : 2.70 Kg
• Country of Origin : India

Mechanical Properties

• Operation Temperature : -10°C to +70°C
• Storage Temperature : 0°C to +50°C
• Bending Radius : <25.4 mm at -20°C to ±1°C
• Pulling Force : 11.5 Kgs

Package Content

• Cable : 100 Meter x 1U
